Image Sensor
|
1/2.7" Progressive Scan CMOS
|
|
Shutter Speed
|
Self-adaptive shutter
|
|
Lens
|
4mm @ F2.0, viewing angle: 46° (Vertical), 89° (Horizontal), 104° (Diagonal) 6mm @ F2.0, viewing angle: 28° (Vertical), 52° (Horizontal), 60° (Diagonal)
|
|
PT Angle
|
Pan: 350°, Tilt: 80°
|
|
Minimum Illumination
|
0.5 Lux @ (F1.6, AGC ON), 0 Lux with IR (Data is obtained from EZVIZ laboratories)
|
|
Day & Night
|
IR-Cut filter with auto-switching
|
|
Lens Mount
|
M12
|
|
Night Vision Distance
|
30 m
|
|
WDR
|
Digital WDR
|
|
DNR
|
3D DNR
|
|
Max. Resolution
|
1920 × 1080
|
|
Frame Rate
|
Max: 30fps; Self-Adaptive during network transmission
|
|
Video Compression
|
H.265 / H.264
|
|
H.265 Type
|
Main Profile
|
|
Video Bit Rate
|
Full HD; Hi-Def; Standard. Adaptive bit rate.
|
|
Max. Bitrate
|
2 Mbps
|
|
Wi-Fi Standard
|
IEEE802.11b, 802.11g, 802.11n
|
|
Frequency Range
|
2.4 GHz
|
|
Transmission Rate
|
11b: 11 Mbps,11g: 54 Mbps,11n: 72 Mbps
|
|
Wired Network
|
RJ45 × 1 (10M / 100M Adaptive Ethernet Port)
|
|
Local Storage
|
MicroSD card slot (Up to 512GB)
|
|
Cloud Storage
|
EZVIZ Cloud Storage (Subscription Required)
|
|
General Function
|
Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark
|
|
Smart Alarm
|
AI-Powered Human Shape Detection
|
|
IP Grade
|
Weatherproof Design
|
|
Power Supply
|
DC 12V / 1A
|
|
Power Consumption
|
MAX. 12W
|
|
Dimensions
|
100.05 × 129.19 × 149.75 mm
|
|
Weight
|
420 g
|
|
In the box
|
H8c Camera, Drill Template, Screw Kit, Waterproof Kit, Power Adapter, Regulatory Information, Quick Start Guide
|
