HPE Aruba 8320 Switch 32-porte 40 Gigabit Ethernet
HPE Aruba 8320 - Switch - L3 - Administreret - 32 x 40 Gigabit QSFP+ - monterbar på stativ - TAA-kompatibel - med X472 5 Fans 2 Power Supply
8320 giver avanceret line rate 10GbE/40GbE i en kompakt 1U formfaktor. 8320 er baseret på ArubaOS-CX, et moderne softwaresystem til virksomhedskernen, der automatiserer og forenkler mange kritiske og komplekse netværksopgaver, leverer forbedret fejltolerance og muliggør nul serviceforstyrrelser under planlagte eller uplanlagte kontrolplanhændelser. Network Analytics Engine-frameworket består af en tidsseriedatabase og tilhørende REST API'er.
-
Product no 996809759
Model JL579A#ABB
Brand Hewlett Packard Ente
EAN 0190017251455
Weight 9.7 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | HPE Aruba 8320 - switch - 32 porte - Administreret - monterbar på stativ - TAA-kompatibel - med X472 5 Fans 2 Power Supply |
| Enhedstype | Switch - 32 porte - L3 - Administreret - med X472 5 Fans 2 Power Supply |
| Pakningstype | Monterbar på stativ 1U |
| Undertype | 40 Gigabit Ethernet |
| Porte | 32 x 40 Gigabit QSFP+ |
| Præstation | Omkoblingskapacitet: 2,5 Tbps<br>Fremsendelsespræstation: 1,905 Mpps |
| Kapacitet | Virtuelle interfaces (VLANs) pr. port for 802.1q: 4096 |
| MAC adresse table størrelse | 14K indtastningshukommelse |
| Jumborammesupport | 9KB |
| Routingprotokol | OSPF, IGMPv2, IGMP, VRRP, IGMPv3, GRE, statisk IPv6 routing, ECMP |
| Protokol til fjernadministration | SNMP, RMON, SNMP 3, SNMP 2c, TFTP, SSH, CLI, SFTP |
| Egenskaber | VPN support, IPv6 understøttet, sFlow, STP support, RSTP support, MSTP support, ACL support, QoS, UDLD, Rapid PVST+, IPv4 support, LACP, overskydende hot swappable blæsere, pakkestormbeskyttelse, SP, Loopback, BPDU, MLAG, PIM |
| Overensstemmelsesstandarder | IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1t, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3ba, IEEE 802.1AX |
| Effekt | AC 120/230 V (50/65 Hz) |
| Overskudsspænding | Ja |
| Dimensioner (B x D x H) | 43.8 cm x 51.5 cm x 4.35 cm |
| Vægt | 9.7 kg |
| Lokalisering | Engelsk / Europa |
| TAA kompatibel | Ja |
| Producentgaranti | 5 års garanti |
Porttilslutning med høj densitet
Leveres med 48 10G-porte til understøttelse af SFP- og SFP+-transceivere og 6 40G-porte til understøttelse af QSFP+-transceivere.
Jumbo-rammer
Tillader højtydende backups og disaster-recovery-systemer; giver en maksimal rammestørrelse på 9K bytes.
Loopback
Understøtter intern loopback-test til vedligeholdelsesformål og øget tilgængelighed; loopback-detektering beskytter mod forkert kabling eller netværkskonfigurationer og kan aktiveres pr. port eller pr. VLAN for ekstra fleksibilitet.
Fleksibelt portvalg
Giver en kombination af fiber- og kobbertransceiver til understøttelse af 1000BASE-T og 10GBASE-T kobberløsning.
Beskyttelse mod pakkestorm
Beskytter mod ukendte broadcast-, ukendte multicast- eller unicast-storme med brugerdefinerede tærskler.
Redundante og belastningsdelende blæsere og strømforsyninger
Øger den samlede ydeevne og strømtilgængelighed og giver samtidig hitless, stateful failover.
Alle hot-swappable moduler
Muliggør udskiftning af moduler uden at påvirke andre moduler.
Separate data- og kontrolstier
Adskiller kontrol fra tjenester og holder behandling af tjenester isoleret; øger sikkerhed og ydeevne.
VRRP
Giver grupper af to routere mulighed for dynamisk at bakke hinanden op for at skabe højtilgængelige routermiljøer.
Unidirektionel linkdetektering (UDLD)
Overvåger linkforbindelse og lukker porte i begge ender, hvis der registreres ensrettet trafik, hvilket forhindrer loops i STP-baserede netværk.
HPE Aruba Networking CX 8320 32 40G QSFP+ with X472 5 Fans 2 Power Supply Switch Bundle
Game-changing business agility
- The HPE Aruba Networking CX 8320 Switch Series is a campus core and aggregation switch solution with an innovative and powerful approach to dealing with the new applications, security and scalability demands of the mobile, cloud and Internet of Things (IoT) era.
- Fully programmable with HPE Aruba Networking CX Switch Operating System (AOS-CX), it brings automation and visibility and helps troubleshoot through simple scripting.
- HPE Aruba Networking CX Network Analytics Engine (NAE) provides the ability to monitor and troubleshoot the network, system, application and security related issues easily, through simple Python agents and REST APIs.
- The switch series offers high-speed fully distributed architecture with 2.5 Tbps switching capacity for uninterrupted networking.
- It provides robust security and quality of service (QoS) with advanced Layer 2 and Layer 3 features including support for BGP, OSPF, and VRF.
Modern software system simplifies and automates
- The CX 8320 series is based on HPE Aruba Networking CX Switch Operating System (AOS-CX), a modern software system for the core that automates and simplifies many critical and complex network tasks.
- The built-in time series database enables customers and developers to develop software modules for historical troubleshooting, as well as analysis of historical trends, to predict and avoid future problems due to scale, security and performance bottlenecks.
- It includes stability, independent monitoring and restart of individual software modules, enhanced software process serviceability functions and it allows individual software modules to be upgraded for higher availability.
- HPE Aruba Networking Switch Multi‑Edit Software support for automated configuration and verification.
- HPE Aruba Networking NetEdit for switch configuration automation and orchestration.
High performance and high availability
- The HPE Aruba Networking CX 8320 Switch Series includes a high speed, fully distributed architecture and provides up to 2.5 Tbps switching capacity to meet the demands and bandwidth-intensive applications today and in the future.
- High availability with HPE Aruba Networking Virtual Switching Extension (VSX) is designed to deliver continuous availability, virtualization and simplicity requirements unique to the core of the network. Redundant and hot-swappable power supplies and fans provide additional resiliency.
- This compact 1U switch delivers line rate 10GbE and 40GbE connectivity with very low latency for support of full internet routes. Optimize for your deployment with a model that provides 32 ports of 40GbE, and models with 48 ports of 10GbE (SFP/SFP+ or 10GBASE-T) and 6 ports of 40GbE.
Specifications
| TechnicalSpecifications | |
|---|---|
| Ports | Supports 32 ports of 40G for use with QSFP+ transceivers (optional 4 x 10G breakout cables) |
| Memory and processor | 2 GHz CPU, 16 GB RAM, 64 GB SSD, and 8 GB Flash |
| Throughput | 1905 Mpps |
| Switching capacity | 2.5 Tbps |
| Management features | SNMP RJ-45 for serial console USB Type-A for file management only RJ-45 Ethernet for OOBM |
| Power supply | Field‑replaceable, hot‑swappable, and up to 2 power supplies |
| Input voltage | 100-127 and 200-240 VAC with either 50 or 60 Hz |
| Power consumption | 310W |
| Product dimensions (metric) | 43.5 x 438 x 515 mm |
| Weight | 9.7 kg |
