XPG PYLON Strømforsyning 750Watt

XPG PYLON - Strømforsyning (intern) - ATX12V 2.52 - 80 PLUS Bronze - AC 90-264 V - 750 watt - Europa

Varenummer: 998672578
Model: PYLON750B-BKCEU
EAN: 4710273776965
Brand:
ADATA Technology
Vægt: 1.6 kg

Specifications

Produktbeskrivelse
XPG PYLON - strømforsyning - 750 watt
Enhedstype
Strømforsyning - intern
Specifikationsoverensstemmelse
ATX12V 2.52
80 PLUS certificering
80 PLUS Bronze
Lokalisering
Europa
Indgangspænding
AC 90-264 V
Strømkapacitet
750 watt
Output-stikforbindelser
2 x strøm 24 pin ATX<br>2 x strøm 8 pin EPS12 V med aftagelig 4 pin ATX12V sektion<br>8 x 15 pin Serial ATA strøm<br>4 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion<br>3 x 4-PIN intern strøm<br>1 x 4-PIN mini-strømforsyningsforbinder
Kølesystem
120 mm ventilator
Dimensioner (B x D x H)
15 cm x 14 cm x 8.6 cm
Producentgaranti
3 års garanti
Specifications

Full specifications

General
Device Type
Power supply - internal
Localization
Europe
PSU Form Factor
ATX
Specification Compliance
ATX12V 2.52
Power Device
80 PLUS Certification
80 PLUS Bronze
Frequency Required
47 - 63 Hz
Input Voltage
AC 90-264 V
Power Capacity
750 Watt
Power Factor (PF)
0.99
Power Output Connectors Details
2 x power 24 pin ATX | 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section | 8 x 15 pin Serial ATA power | 4 x 8 pin PCI Express power with detachable 2 pin section | 3 x 4 pin internal power | 1 x 4 pin mini-power connector
Miscellaneous
Compliant Standards
TUV, BSMI, TUV S, CCC, EMC, FCC, RoHS, cTUVus, EAC, RCM, Energy-Related Products (ErP) Lot 3, CB 60950, CB 62368
Cooling System
120 mm fan
Features
Overcurrent protection, overvoltage protection, overpower protection, undervoltage protection, short-circuit protection, no load operation protection, Surge &amp; Inrush Protection (SIP)
MTBF
100,000 hours
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight
Depth
14 cm
Height
8.6 cm
Width
15 cm
