Ubiquiti UniFi Switch USW-Enterprise-48- Switch 48-porte 2.5 Gigabit PoE+
Switch Enterprise 48 PoE (USW Enterprise 48 PoE) er en fuldt administreret switch med (48) 2,5 GbE, 802.3at PoE+ RJ45-porte, (4) 10G SFP+-porte og en samlet 720 W PoE-forsyning. Sammen med sin Layer 3-funktionalitet tilbyder denne switch en omfattende pakke af Layer 2-switching-protokoller, herunder portspecifikke driftstilstande (switching, spejling eller aggregering). USW Enterprise 48 PoE har også en 1,3" LCM-farvetouchskærm, der kortfattet viser vigtige system- og forbindelsesoplysninger.
-
Product no 999609167
Model USW-ENTERPRISE-48-PO
Brand
Go to brand's websiteEAN 0810010074768
Weight 8.01 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | Ubiquiti UniFi Switch USW-Enterprise-48-PoE - switch - 48 porte - Administreret - monterbar på stativ |
| Enhedstype | Switch - 48 porte - L3 - Administreret |
| Pakningstype | Monterbar på stativ |
| Undertype | 2.5 Gigabit Ethernet |
| Porte | 48 x 100/1000/2.5G (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE-budget | 720 W |
| Præstation | Ikke-blokerende switching-gennemløb: 160 Gbps<br>Omkoblingskapacitet: 320 Gbps<br>Videresendelseshastighed: 238.095 Mpps |
| Egenskaber | Portspejling, firmware kan opgraderes, nulstillingsknap, Link Aggregation, 12KV ESD Protector (kontaktafladning), 16KV ESD Protector (lufthulsafladning), stålkabinet |
| Overensstemmelsesstandarder | IEEE 802.3af, IEEE 802.3at |
| Effekt | AC 100-240 V (50/60 Hz) |
| Dimensioner (B x D x H) | 44.2 cm x 40 cm x 4.4 cm |
| Vægt | 6.2 kg |
| General | |
|---|---|
| Built-in Devices | 1.3" touch screen display |
| Compliant Standards | IEEE 802.3af, IEEE 802.3at |
| Device Type | Switch - 48 ports - L3 - managed |
| Enclosure Type | Rack-mountable |
| Features | Port mirroring, firmware upgradable, reset button, Link Aggregation, 12KV ESD Protector (contact discharge), 16KV ESD Protector (air-gap discharge), steel housing |
| Performance | Non-blocking switching throughput: 160 Gbps | Switching capacity: 320 Gbps | Forwarding rate: 238.095 Mpps |
| PoE Budget | 720 W |
| Ports | 48 x 100/1000/2.5G (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink) |
| Power Over Ethernet (PoE) | PoE+ |
| Status Indicators | Link/activity |
| Subtype | 2.5 Gigabit Ethernet |
| Expansion / Connectivity | |
| Interfaces | 48 x 100/1000/2.5G RJ-45 PoE+ - 34.2 W | 4 x 1/10Gbit LAN SFP+ uplink |
| Power | |
| Features | Redundant Power System (RPS) connector |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Miscellaneous | |
| Compliant Standards | IC, FCC |
| Rack Mounting Kit | Included |
| Dimensions & Weight | |
| Depth | 40 cm |
| Height | 4.4 cm |
| Weight | 6.2 kg |
| Width | 44.2 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | -5 °C |
