TRENDnet TI-G642I Switch 6-porte Gigabit
TRENDnet TI-G642I - Switch - Administreret - 4 x 10/100/1000 + 2 x Gigabit SFP - DIN monterbar på skinne - DC strøm - TAA-kompatibel
Varenummer:
994884232
Model:
TI-G642I
EAN:
0710931161540
Brand:
Vægt:
1.04 kg
Specifications
|
Produktbeskrivelse
|
TRENDnet TI-G642I - switch - 6 porte - Administreret - TAA-kompatibel
|
|
Enhedstype
|
Switch - 6 porte - Administreret
|
|
Undertype
|
Gigabit Ethernet
|
|
Porte
|
4 x 10/100/1000 + 2 x Gigabit SFP
|
|
Præstation
|
Skift af stofbåndbredde: 12 Gbps<br>Videresendelsespræstation (64-byte pakkestørrelse): 18,9 Mpps
|
|
MAC adresse table størrelse
|
8K indtastningshukommelse
|
|
Jumborammesupport
|
10KB
|
|
Routingprotokol
|
IGMPv2, IGMP, IGMPv3
|
|
Protokol til fjernadministration
|
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, SSH-2, CLI
|
|
Egenskaber
|
Auto-negotiation, Syslog understøttet, portspejling, gem og send, halv dupleksmodus, fuld dupleksmodus, DDMI, STP support, RSTP support, DHCP snooping, DHCP server, nulstillingsknap, båndbreddekontrol, blæserløs, LLDP support, DHCP videresendelse, CoS, 8KV ESD Protector, metalkabinet, DSCP support, køplanlægningssupport
|
|
Overensstemmelsesstandarder
|
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX
|
|
Effekt
|
DC 20 - 60 V - strømadapter ikke inkluderet
|
|
Overskudsspænding
|
Ja
|
|
Dimensioner (B x D x H)
|
5 cm x 12 cm x 16 cm
|
|
Vægt
|
720 g
|
|
TAA kompatibel
|
Ja
|
|
Producentgaranti
|
Begrænset livtidsgaranti
|
Full specifications
|
General
|
|
|---|---|
|
Compliant Standards
|
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX
|
|
Device Type
|
Switch - 6 ports - unmanaged
|
|
Enclosure Type
|
DIN rail mountable
|
|
Features
|
Auto-negotiation, Syslog support, port mirroring, store and forward, half duplex mode, full duplex mode, Digital Diagnostics Monitoring Interface (DDMI), Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping
|
|
Jumbo Frame Support
|
10KB
|
|
MAC Address Table Size
|
8K entries
|
|
Performance
|
Switching fabric bandwidth: 12 Gbps | Forwarding performance (64-byte packet size): 18.9 Mpps
|
|
Ports
|
4 x 10/100/1000 + 2 x Gigabit SFP
|
|
RAM
|
128 MB
|
|
Remote Management Protocol
|
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, SSH-2, CLI
|
|
Routing Protocol
|
IGMPv2, IGMP, IGMPv3
|
|
Subtype
|
Gigabit Ethernet
|
|
Expansion / Connectivity
|
|
|
Interfaces
|
4 x 1000Base-T RJ-45 | 2 x Gigabit LAN SFP
|
|
Power
|
|
|
Max Supported Qty
|
2
|
|
Power Consumption Operational
|
12 Watt
|
|
Power Device
|
External power adapter (not included)
|
|
Power Redundancy
|
Yes
|
|
Voltage Required
|
DC 20 - 60 V
|
|
Miscellaneous
|
|
|
Compliant Standards
|
FCC, IP30, EN 60068-2-27, EN 60068-2-32, EN 60068-2-6
|
|
Included Accessories
|
DIN-rail mounting kit, removable terminal block
|
|
MTBF
|
996,299 hours
|
|
Dimensions & Weight
|
|
|
Depth
|
12 cm
|
|
Height
|
16 cm
|
|
Weight
|
720 g
|
|
Width
|
5 cm
|
|
Manufacturer Warranty
|
|
|
Service & Support
|
Limited warranty - lifetime
|
|
Environmental Parameters
|
|
|
Humidity Range Operating
|
95% (non-condensing)
|
|
Max Operating Temperature
|
75 °C
|
|
Min Operating Temperature
|
-40 °C
|
