StarTech.com Netværksadapter ExpressCard/34 1Gbps

Startech Dual Port ExpressCard Gigabit Laptop Ethernet NIC Network Adapter Card - Netværksadapter - ExpressCard - Gigabit Ethernet x 2

  • Product no 988492673

    Model EC2000S

    Brand StarTech.com

    EAN 0065030843669

    Weight 0.12 kg

  • Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Produktbeskrivelse Startech Dual Port ExpressCard Gigabit Laptop Ethernet NIC Network Adapter Card - netværksadapter - ExpressCard - Gigabit Ethernet x 2
Enhedstype Netværksadapter
Model Indstiksmodul
Grænseflade (bus) type ExpressCard/34
Porte Gigabit Ethernet x 2
Dimensioner (B x D x H) 3.4 cm x 11.6 cm x 2.1 cm
Vægt 150 g
Kabeltype Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Dataforbindelsesprotokol 10Mb LAN, 100Mb LAN, 1GbE
Dataoverførselshastighed 1 Gbps
Netværks/overføselsprotokol TCP/IP, UDP/IP
Processor 1 x Realtek Semiconductor RTL8111E
Overensstemmelsesstandarder IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x
Systemkrav Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Apple MacOS X 10.6 - 10.9, Microsoft Windows Server 2016, Microsoft Windows 2000/XP/Vista/7/8/8.1/10, Linux 2.4.x to 4.11.x LTS versions only, Microsoft Windows Server 2019
Producentgaranti Begrænset livtidsgaranti
General
Device Type Network adapter
Form Factor Plug-in module
Interface (Bus) Type ExpressCard/34
Networking
Cabling Type Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x
Connectivity Technology Wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate 1 Gbps
Features Flow control, full duplex capability, remote Wake Up, hot swap module replacement, auto-negotiation, wake on LAN (WOL), auto-uplink (auto MDI/MDI-X), half duplex mode, Jumbo Frames support
Network / Transport Protocol TCP/IP, UDP/IP
Ports Gigabit Ethernet x 2
Status Indicators Port transmission speed, link/activity
Processor / Memory
Processor 1 x Realtek Semiconductor RTL8111E
Expansion / Connectivity
Compatible Slots 1 x ExpressCard/34
Interfaces 2 x 1000Base-T - RJ-45
Miscellaneous
Compliant Standards Plug and Play, FCC, RoHS
Software / System Requirements
OS Required Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Apple MacOS X 10.6 - 10.9, Microsoft Windows Server 2016, Microsoft Windows 2000/XP/Vista/7/8/8.1/10, Linux 2.4.x to 4.1
Software Included Drivers & Utilities
Dimensions & Weight
Depth 11.6 cm
Height 2.1 cm
Weight 150 g
Width 3.4 cm
Manufacturer Warranty
Service & Support Limited warranty - lifetime
Environmental Parameters
Humidity Range Operating 5 - 95%
Max Operating Temperature 55 °C
Min Operating Temperature 0 °C

Add 2 Gigabit Ethernet ports to your laptop, through a single ExpressCard slot

  • Dual RJ45 Ethernet ports in an ExpressCard/34 adapter
  • Fully compliant with IEEE 802.3, 802.3u, and 802.3ab specifications for 10/100/1000 Mbps connections
  • Supports Full and Half duplex operating modes
Add 2 Gigabit Ethernet ports to your laptop, through a single ExpressCard slot
slide {0} of {1}, zoom in, Add 2 Gigabit Ethernet ports to your laptop, through a single ExpressCard slot
slide {0} of {1}, zoom in, Add 2 Gigabit Ethernet ports to your laptop, through a single ExpressCard slot
slide {0} of {1}, zoom in, Add 2 Gigabit Ethernet ports to your laptop, through a single ExpressCard slot
slide {0} of {1}, zoom in, Add 2 Gigabit Ethernet ports to your laptop, through a single ExpressCard slot
Provides two independent 10/100/1000 Mbps Ethernet interfaces, from a single ExpressCard slot

Provides two independent 10/100/1000 Mbps Ethernet interfaces, from a single ExpressCard slot

The EC2000S 2-port Gigabit ExpressCard Ethernet Adapter adds 2 10/100/1000Mbps Ethernet ports to an ExpressCard-enabled laptop, or small form factor system, enabling you to connect to two separate physical networks simultaneously with dedicated bandwidth, or providing full dedicated bandwidth to virtual machines.
Use less system resources with built-in NDIS5 Checksum and Large Send Offload support and Jumbo Frames

Use less system resources with built-in NDIS5 Checksum and Large Send Offload support and Jumbo Frames

Supporting features such as NDIS5 checksum and large send offload for lower CPU utilization, Wake-on-LAN (WOL) and Remote Wake-up power management, jumbo frames and VLAN tagging, this ExpressCard Ethernet Adapter is ready to handle a wide variety of scenarios.
Guaranteed Reliability

Guaranteed Reliability

With a 34mm ExpressCard form factor, this compact and portable Gigabit Ethernet Adapter will fit in any ExpressCard-enabled system, and is backed by a StarTech.com lifetime warranty and free lifetime technical support.

Applications

  • Business or IT professionals that need to connect to two separate networks simultaneously
  • Run a virtual machine(s) on a workstation, with access to separate physical network connections
  • Replacement for a failed built-in Gigabit Ethernet port on a laptop
