Produktbeskrivelse
|
Startech Extreme Networks 10302 Compatible SFP+ Module, 10GBASE-LR, 10GbE Single Mode (SMF) Fiber Optic Transceiver, 10GE Gigabit Ethernet SFP+, LC 10km, 1310nm, DDM, Mini GBIC Module - Lifetime Warranty (10302-ST) - SFP+ transceiver modul - 10GbE
|
|
Enhedstype
|
SFP+ transceiver modul - LC enkelttilstand
|
|
Model
|
Indstiksmodul
|
|
Kabeltype
|
10GBase-LR
|
|
Dataoverførselshastighed
|
10 Gbps
|
|
Optisk bølgelængde
|
1310 nm
|
|
Dataforbindelsesprotokol
|
10GbE
|
|
Maks. overføringsafstand
|
10 km
|
|
OEM-producentækvivalent delnummer
|
Extreme Networks 10302
|
|
Dimensioner (B x D x H)
|
5.84 cm x 1.39 cm x 1.37 cm
|
|
Vægt
|
21 g
|
|
Producentgaranti
|
Begrænset livtidsgaranti
|
Effective Friday, July 3, 2026, the office will close at 4:30 PM on Fridays. From Monday to Thursday, Sales contact hours remain unchanged from 9:00 AM to 5:00 PM, while contact hours for Accounting, Purchasing, and RMA remain unchanged in general.
To gain full access to our webshop, find our entire product range and see our prices, you need to be logged in.
Log in to your account here or sign up as a customer here.
StarTech.com Extreme Networks 10302 Compatible SFP Module - 10GBASE-LR - 10GE SFP 10GbE Single Mode Fiber SMF Optic Transceiver 10km DDM SFP+ transceiver modul 10 Gigabit Ethernet
Startech Extreme Networks 10302 Compatible SFP+ Module, 10GBASE-LR, 10GbE Single Mode (SMF) Fiber Optic Transceiver, 10GE Gigabit Ethernet SFP+, LC 10km, 1310nm, DDM, Mini GBIC Module - Lifetime Warranty (10302-ST) - SFP+ transceiver modul (svarende til: Extreme Networks 10302) - 10GbE - 10GBase-LR - LC enkelttilstand - op til 10 km - 1310 nm
Specifications
Full specifications
|
General
|
|
|---|---|
|
Device Type
|
SFP+ transceiver module
|
|
Form Factor
|
Plug-in module
|
|
Networking
|
|
|
Cabling Type
|
10GBase-LR
|
|
Connectivity Technology
|
Wired
|
|
Data Link Protocol
|
10 GigE
|
|
Data Transfer Rate
|
10 Gbps
|
|
Features
|
Full duplex mode, Digital Diagnostics Monitoring (DDM)
|
|
Max Transfer Distance
|
10 km
|
|
Optical Wave Length
|
1310 nm
|
|
Expansion / Connectivity
|
|
|
Interfaces
|
1 x Ethernet 10GBase-LR - LC single-mode female x 2
|
|
Miscellaneous
|
|
|
Compliant Standards
|
FCC, MSA
|
|
MTBF
|
1,386,624,697 hours
|
|
OEM Manufacturer Equivalent Part Number
|
Extreme Networks 10302
|
|
Power
|
|
|
Power Consumption Operational
|
1.3 Watt
|
|
Dimensions & Weight
|
|
|
Depth
|
1.39 cm
|
|
Height
|
1.37 cm
|
|
Weight
|
21 g
|
|
Width
|
5.84 cm
|
|
Dimensions & Weight (Shipping)
|
|
|
Shipping Depth
|
11.5 cm
|
|
Shipping Height
|
3.1 cm
|
|
Shipping Weight
|
50 g
|
|
Shipping Width
|
9 cm
|
|
Manufacturer Warranty
|
|
|
Service & Support
|
Limited warranty - lifetime
|
Media
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
The 10302-ST is an Extreme Networks 10302 compatible fiber transceiver module that has been designed, programmed and tested to work with Extreme Networks brand switches and routers. It delivers dependable 10 GbE connectivity over fiber cable, for 10GBase-LR compliant networks, with a maximum distance of up to 10 km (6.2 mi).
Technical Specifications:
- Wavelength: 1310 nm
- Maximum Data Transfer Rate: 10 Gbps
- Type: Single Mode Fiber
- Connection Type: LC Connector
- Maximum Transfer Distance: 10 km (6.2 mi)
- MTBF: 1,386,624,697 hours
- Power Consumption: < 1.3W
- Digital Diagnostics Monitoring (DDM): Yes
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
