QNAP TS-h1290FX 12Moduler

QNAP TS-h1290FX - NAS-server - 12 bays - SATA 6Gb/s / PCIe (NVMe) / U.2 - RAM 128 GB - 25 Gigabit Ethernet / 2.5 Gigabit Ethernet - iSCSI support

Product no: 999865803
Model: TS-H1290FX-7302P-128
EAN: 4711103080528
Brand:
"QNAP Systems, Inc"
Weight: 8.99 kg

Specifications

Produktbeskrivelse
QNAP TS-h1290FX - NAS-server
Enhedstype
NAS-server
Vært Tilslutning
25 Gigabit Ethernet / 2.5 Gigabit Ethernet
Installeret udstyr/antal moduler
0 (installeret) / 12 (maks.)
Dimensioner (B x D x H)
36.8 cm x 36.2 cm x 15 cm
Vægt
8.99 kg (uden HDD)
Processor
1 x AMD EPYC 7302P 3 GHz (16-core)
Controller for lagring
RAID SATA 6Gb/s / PCIe (NVMe) / U.2
Netværk
2.5GbE, 25GbE
RAM
128 GB
Effekt
AC 100-240 V
Producentgaranti
5 års garanti
Specifications

Full specifications

General
Built-in Devices
Status LCD
Depth
36.2 cm
Device Type
NAS server
Height
15 cm
Host Connectivity
25 Gigabit Ethernet / 2.5 Gigabit Ethernet
Installed Devices / Modules Qty
0 (installed) / 12 (max)
Total Storage Capacity
0 GB
Weight
8.99 kg (without HDD)
Width
36.8 cm
Processor / Memory
Features
ECC
Flash Memory Installed
5 GB
Max Supported Qty
1
Max Turbo Speed
3.3 GHz
Number of Cores
16-core
Processors Installed
1 x AMD EPYC 7302P 3 GHz
RAM
128 GB (installed) / 1 TB (supported) - DDR4
Storage Controller
Interface Type
SATA 6Gb/s / PCIe (NVMe) / U.2
Type
RAID
Networking
Data Link Protocol
2.5 GigE, 25 Gigabit Ethernet
Encryption Algorithm
AES-NI
Features
Wake on LAN (WOL), Jumbo Frames support, Single Root I/O Virtualization (SR-IOV), WORM (Write Once Read Many protection), 8K resolution support
Expansion / Connectivity
Expansion Bays
12 (total) / 12 (free) x hot-swap - 2.5"
Expansion Slots
3 x PCI Express 4.0 x16 | 1 x PCI Express 4.0 x8
Interfaces
4 x 2.5 Gigabit Ethernet - RJ-45 | 3 x USB 3.2 Gen 1 - Type A | 2 x Ethernet 25Gb - SFP28
Miscellaneous
Cables Included
1 x network cable
Features
Security lock slot (cable lock sold separately), audible alarm, built-in 2 cooling fans, reset button, dual boot
Included Accessories
48 x flat head screws (for 2.5" HDD), power cable, 2 x drive tray keys
Security Slot Type
Kensington security slot
Power
Power Device
Internal power supply
Power Provided
750 Watt
Voltage Required
AC 100-240 V
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Humidity Range Operating
5 - 95% RH (non-condensing)
Max Operating Temperature
40 °C
Min Operating Temperature
0 °C
