Product no 995534944
Model GS110TP-300EUS
Brand NETGEAR
EAN 0606449137644
Weight 1.51 kg
Produktbeskrivelse | NETGEAR Smart GS110TPv3 - switch - 8 porte - smart |
Enhedstype | Switch - 8 porte - smart |
Undertype | Gigabit Ethernet |
Porte | 8 x 10/100/1000 (PoE) + 2 x SFP |
Power Over Ethernet (PoE) | PoE+ |
PoE-budget | 55 W |
Præstation | Skift af stofbåndbredde: 20 Gbps<br>Videresendelsespræstation (64-byte pakkestørrelse): 14,8 Mpps |
Kapacitet | Pakkebufferstørrelse: 512 KB<br>ACL-indtastninger (indgang): 100<br>VLANs understøttet: 64<br>IPv4 ruter (statisk): 32 |
MAC adresse table størrelse | 8K indtastningshukommelse |
Jumborammesupport | 10KB |
Routingprotokol | IGMPv2, IGMP, IGMPv3, statisk IPv4 routing, MLDv2, MLD |
Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, IPv6 |
Egenskaber | IGMP snooping, Syslog understøttet, DoS attack beskyttelse, portspejling, DiffServ understøttet, gem og send, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware kan opgraderes, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, MDL snooping, blæserløs, LACP, DHCP klient, dobbelt firmware-billeder, løkkeforebyggelse, mærket VLAN, kabeltest, LLDP-MED, beskyttede porte, EEE, WRR, Advanced QoS, Unknown Storm Control, sikkerhedsåbning (Kensington-sikkerhedslåskompatibel) |
Overensstemmelsesstandarder | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
Effekt | DC 54 V |
Dimensioner (B x D x H) | 23.6 cm x 10.1 cm x 2.7 cm |
Vægt | 610 g |
Lokalisering | Europa |
Producentgaranti | NETGEAR livstids garanti |
General | |
---|---|
Authentication Method | RADIUS, TACACS+ |
Capacity | Packet buffer size: 512 KB | ACL entries (ingress): 100 | VLANs supported: 64 | IPv4 routes (static): 32 |
Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
Device Type | Switch - 8 ports - smart |
Enclosure Type | Desktop, wall-mountable |
Encryption Algorithm | TLS 1.2 |
Features | IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, store and forward, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spann |
Flash Memory | 32 MB |
Jumbo Frame Support | 10KB |
MAC Address Table Size | 8K entries |
Performance | Switching fabric bandwidth: 20 Gbps | Forwarding performance (64-byte packet size): 14.8 Mpps |
PoE Budget | 55 W |
Ports | 8 x 10/100/1000 (PoE) + 2 x SFP |
Power Over Ethernet (PoE) | PoE+ |
Processor | : 500 MHz |
RAM | 128 MB |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, IPv6 |
Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv4 routing, MLDv2, MLD |
Status Indicators | Port status, PoE, link/activity/speed |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 8 x 1000Base-T RJ-45 PoE+ | 2 x 1000Base-X SFP |
Power | |
Power Consumption Operational | 69.5 Watt |
Power Consumption Stand by | 4.3 Watt |
Power Device | External power adapter |
Voltage Required | DC 54 V |
Miscellaneous | |
Included Accessories | Wall mounting kit |
Localization | Europe |
MTBF | 1,200,041 hours |
Dimensions & Weight | |
Depth | 10.1 cm |
Height | 2.7 cm |
Weight | 610 g |
Width | 23.6 cm |
Manufacturer Warranty | |
Service & Support | Limited warranty - replacement - lifetime - response time: next business day | Limited warranty - power supply - 2 years | Technical support - phone consulting - 90 days |
Environmental Parameters | |
Humidity Range Operating | 95% (non-condensing) |
Humidity Range Storage | 95% (non-condensing) |
Max Operating Temperature | 40 °C |
Max Storage Temperature | 70 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -20 °C |
