Produktbeskrivelse
|
MSI MAG A650BN - strømforsyning - 650 watt
|
|
Enhedstype
|
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
|
|
Specifikationsoverensstemmelse
|
ATX12V / EPS12V
|
|
80 PLUS certificering
|
80 PLUS Bronze
|
|
Indgangspænding
|
AC 100-240 V
|
|
Udgangspænding
|
+3.3, +5, ±12 V
|
|
Strømkapacitet
|
650 watt
|
|
Output Current
|
+3.3V - 20 A<br>+5V - 20 A<br>-12V - 0.3 A<br>+5VSB - 2.5 A<br>+12V - 45.5 A
|
|
Output-stikforbindelser
|
1 x strøm 24 pin ATX med aftagelig 4 pin sektion<br>1 x strøm 8 pin EPS12 V med aftagelig 4 pin ATX12V sektion<br>5 x 15 pin Serial ATA strøm<br>2 x 4-PIN intern strøm<br>2 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion<br>1 x 4-PIN mini-strømforsyningsforbinder
|
|
Kølesystem
|
120 mm ventilator
|
|
Dimensioner (B x D x H)
|
15 cm x 14 cm x 8.6 cm
|
|
Producentgaranti
|
5 års garanti
|
We are continuously resolving any minor issues that may arise. Thank you for your patience.
To gain full access to our webshop, find our entire product range and see our prices, you need to be logged in.
Log in to your account here or sign up as a customer here.
MSI MAG A650BN 650Watt 80 PLUS Bronze
MSI MAG A650BN - Strømforsyning (intern) - ATX12V / EPS12V - 80 PLUS Bronze - AC 100-240 V - 650 watt - aktiv PFC
Varenummer:
999584047
Model:
306-7ZP2B11-CE0
EAN:
4719072849627
Brand:
Vægt:
2.07 kg
Specifications
Full specifications
|
General
|
|
|---|---|
|
Device Type
|
Power supply - active Power Factor Correction (PFC) - internal
|
|
PSU Form Factor
|
ATX
|
|
Specification Compliance
|
ATX12V / EPS12V
|
|
Power Device
|
|
|
80 PLUS Certification
|
80 PLUS Bronze
|
|
Efficiency
|
85%
|
|
Frequency Required
|
50 - 60 Hz
|
|
Input Voltage
|
AC 100-240 V
|
|
Output Current
|
+3.3V - 20 A | +5V - 20 A | -12V - 0.3 A | +5VSB - 2.5 A | +12V - 45.5 A
|
|
Output Voltage
|
+3.3, +5, ±12 V
|
|
Power Capacity
|
650 Watt
|
|
Power Output Connectors Details
|
1 x power 24 pin ATX with detachable 4 pin section | 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section | 5 x 15 pin Serial ATA power | 2 x 4 pin internal power | 2 x 8 pin PCI Express power with detachable 2 pin section | 1 x 4 pin mini-pow
|
|
Miscellaneous
|
|
|
Cooling System
|
120 mm fan
|
|
Features
|
Overheat protection, overcurrent protection, overvoltage protection, overpower protection, short-circuit protection, single 12V rail, DC-DC technology, non-modular
|
|
Manufacturer Warranty
|
|
|
Service & Support
|
Limited warranty - 5 years
|
|
Dimensions & Weight
|
|
|
Depth
|
14 cm
|
|
Height
|
8.6 cm
|
|
Width
|
15 cm
|
