LevelOne NVR-1332 Standalone NVR
LevelOne NVR-1332 - NVR - 32 kanaler - netværket
-
Product no 996747545
Model NVR-1332
Brand LevelOne
EAN 4015867201848
Weight 5 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | LevelOne NVR-1332 - standalone NVR - 32 kanaler |
| Enhedstype | NVR - 32 kanaler - netværket |
| Understøttede IP Kameraer | 32 |
| Ramme Rate | 30 fps, 20 fps |
| Komprimerings Format | MPEG-4, H.264, H.265, H.264+ |
| Billed Opløsning | 3840x2160 |
| Understøttede HardDrev | Antal: 4 - total kapacitet: 32 TB |
| Dimensioner (B x D x H) | 44.5 cm x 39 cm x 7 cm |
| Vægt | 5 kg |
| General | |
|---|---|
| Audio Channels | 1 |
| Color | Black |
| Compliant Standards | UL, FCC |
| Compression Format | MPEG-4, H.264, H.265, H.264+ |
| Device Type | NVR |
| Image Resolution | 3840x2160 |
| IP Cameras Supported | 32 |
| OS Provided | Linux |
| Video Channels | 32 |
| Security DVR | |
| Features | Mobile phone monitoring |
| Frame Rate (Record) | 30 fps, 20 fps |
| Networked | Yes |
| Playback Search | Date/time, event |
| Hard Drive | |
| Interface | Serial ATA |
| Quantity Supported | 4 |
| Supported Max Total Capacity | 32 TB |
| Networking | |
| Network Interfaces | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Supported Protocols | DDNS, DHCP, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, SNMP, RTSP, RTP, HTTPS, IPv4, IPv6, PPPoE, SSL, SNTP |
| System Requirements | |
| Browser | Internet Explorer 9 or later |
| Connections | |
| Audio Input Ports | RCA x 1 |
| Audio Output Ports | RCA x 1 |
| Camera Control Interface (PTZ) | RS-485 |
| Network Port | 10/100/1000Base-T x 2 |
| Other Ports | USB 2.0 x 2 |
| Video Output Ports | HDMI x 1, VGA x 1 |
| Power | |
| Power Consumption | 20 Watt |
| Dimensions & Weight | |
| Depth | 39 cm |
| Height | 7 cm |
| Weight | 5 kg |
| Width | 44.5 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | -10 °C |
