LevelOne GVT-2012 Fibermedieomformer Ethernet Fast Ethernet Gigabit Ethernet

LevelOne GVT-2012 - Fibermedieomformer - 1GbE - 10Base-T, 1000Base-SX, 100Base-TX, 1000Base-T - RJ-45 / SFP (mini-GBIC)

Varenummer: 993775379
Model: GVT-2012
EAN: 4015867207345
Brand:
LevelOne
Vægt: 0.2 kg

Specifications

Produktbeskrivelse
LevelOne GVT-2012 - fibermedieomformer - 10Mb LAN, 100Mb LAN, 1GbE
Enhedstype
Fibermedieomformer - RJ-45 / SFP (mini-GBIC)
Model
Ekstern
Kabeltype
10Base-T, 1000Base-SX, 100Base-TX, 1000Base-T
Dataoverførselshastighed
1 Gbps
Dataforbindelsesprotokol
10Mb LAN, 100Mb LAN, 1GbE
Power Over Ethernet (PoE)
PoE
Dimensioner (B x D x H)
9.4 cm x 7 cm x 2.6 cm
Vægt
200 g
Specifications

Full specifications

General
Device Type
Fiber media converter
Form Factor
External
Networking
Cabling Type
10Base-T, 1000Base-SX, 100Base-TX, 1000Base-T
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3x
Connectivity Technology
Wired
Data Link Protocol
10Mb LAN, 100Mb LAN, GigE
Data Transfer Rate
1 Gbps
Features
Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, half duplex mode, full duplex mode, Link Fault Pass Through function (LFP), wall mountable, Jumbo Frames support, built-in DIP switch
Status Indicators
Power, link/activity
Expansion / Connectivity
Interfaces
1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 female - 30 W | 1 x Ethernet 1000Base-SX - SFP
Miscellaneous
Compliant Standards
RoHS
Power
Power Device
External power adapter
Power Over Ethernet (PoE)
PoE
Dimensions & Weight
Depth
7 cm
Height
2.6 cm
Weight
200 g
Width
9.4 cm
Environmental Parameters
Humidity Range Operating
5 - 90% (non-condensing)
Max Operating Temperature
55 °C
Min Operating Temperature
-10 °C
