LevelOne GTP-2871 Switch 28-porte Gigabit PoE+
LevelOne GTP-2871 - Switch - L3 Lite - Administreret - 24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ - desktop, monterbar på stativ - PoE+ (400 W)
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Specifications
|
Produktbeskrivelse
|
LevelOne GTP-2871 - switch - 28 porte - Administreret - monterbar på stativ
|
|
Enhedstype
|
Switch - 28 porte - L3 Lite - Administreret
|
|
Pakningstype
|
Monterbar på stativ 1U
|
|
Undertype
|
Gigabit Ethernet
|
|
Porte
|
24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
|
|
Power Over Ethernet (PoE)
|
PoE+
|
|
PoE-budget
|
400 W
|
|
Præstation
|
Skift af båndbredde: 128 Gbps<br>Fremsendelsespræstation: 95,232 Mpps
|
|
MAC adresse table størrelse
|
16K indtastningshukommelse
|
|
Jumborammesupport
|
10KB
|
|
Routingprotokol
|
IGMPv2, IGMP, IGMPv3
|
|
Protokol til fjernadministration
|
SNMP 1, RMON 1, RMON 2, SNMP, RMON 9, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, CLI
|
|
Egenskaber
|
Datatransport, VLAN-understøttet, IGMP snooping, Syslog understøttet, portspejling, gem og send, IPv6 understøttet, sFlow, STP support, RSTP support, MSTP support, PAgP support, ACL support, QoS, DHCP server, nulstillingsknap, STP Root Guard, IPv4 support, LACP support, DHCP videresendelse, Port Security, DHCP klient, Energy Efficient Ethernet, NAC, løkkeforebyggelse, mærket VLAN, GVRP, 4 MB pakkebuffer, 802.1x autentificering, 1,5 MB pakkebuffer, Storm Control, IP-kildebekyttelse, NTP
|
|
Overensstemmelsesstandarder
|
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az, UPnP
|
|
Effekt
|
AC 120/230 V (50/60 Hz)
|
Full specifications
|
General
|
|
|---|---|
|
Authentication Method
|
Secure Shell (SSH), RADIUS, TACACS+
|
|
Compliant Standards
|
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az, UPnP
|
|
Device Type
|
Switch - 28 ports - L3 Lite - managed
|
|
Enclosure Type
|
Desktop, rack-mountable 1U
|
|
Encryption Algorithm
|
SSL
|
|
Features
|
Flow control, VLAN support, IGMP snooping, Syslog support, port mirroring, store and forward, IPv6 support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Port
|
|
Flash Memory
|
32 MB
|
|
Jumbo Frame Support
|
10KB
|
|
MAC Address Table Size
|
16K entries
|
|
Performance
|
Switching bandwidth: 128 Gbps | Forwarding performance: 95.232 Mpps
|
|
PoE Budget
|
400 W
|
|
Ports
|
24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
|
|
Power Over Ethernet (PoE)
|
PoE+
|
|
RAM
|
512 MB
|
|
Remote Management Protocol
|
SNMP 1, RMON 1, RMON 2, SNMP, RMON 9, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, CLI
|
|
Routing Protocol
|
IGMPv2, IGMP, IGMPv3
|
|
Status Indicators
|
Port transmission speed, system, PoE, link/activity
|
|
Subtype
|
Gigabit Ethernet
|
|
Expansion / Connectivity
|
|
|
Interfaces
|
24 x 1000Base-T RJ-45 PoE+ - 30 W | 4 x 10Gbit LAN SFP+ | 1 x console RJ-45
|
|
Power
|
|
|
Power Device
|
Internal power supply
|
|
Voltage Required
|
AC 120/230 V (50/60 Hz)
|
|
Miscellaneous
|
|
|
Cables Included
|
1 x console cable
|
|
Included Accessories
|
Rubber feet
|
|
MTBF
|
150,000 hours
|
|
Rack Mounting Kit
|
Included
|
|
Environmental Parameters
|
|
|
Humidity Range Operating
|
5 - 95% (non-condensing)
|
|
Humidity Range Storage
|
5 - 95% (non-condensing)
|
|
Max Operating Temperature
|
45 °C
|
|
Max Storage Temperature
|
70 °C
|
|
Min Operating Temperature
|
0 °C
|
|
Min Storage Temperature
|
-40 °C
|
