Produktbeskrivelse
|
HPE Aruba 9004 (RW) - gateway - ZigBee, NFC, Bluetooth - cloud-administreret
|
|
Enhedstype
|
Gateway
|
|
Formfaktor
|
Ekstern
|
|
Antal porte
|
4
|
|
Dataforbindelsesprotokol
|
Gigabit Ethernet, ZigBee, NFC, Bluetooth 5.0
|
|
Præstation
|
Firewall-gennemløb: 2 Gbps<br>Bro-gennemløb: 4 Gbps
|
|
Kapacitet
|
Antal understøttede enheder: 2048<br>Aktive firewall sessioner: 32426
|
|
Effekt
|
AC 120/230 V (50/60 Hz)
|
|
Pristype
|
BTO
|
|
Dimensioner (B x D x H)
|
19.85 cm x 15.31 cm x 3.82 cm
|
|
Vægt
|
1.143 kg
|
|
Producentgaranti
|
1 års garanti
|
Effective Friday, July 3, 2026, the office will close at 4:30 PM on Fridays. From Monday to Thursday, Sales contact hours remain unchanged from 9:00 AM to 5:00 PM, while contact hours for Accounting, Purchasing, and RMA remain unchanged in general.
To gain full access to our webshop, find our entire product range and see our prices, you need to be logged in.
Log in to your account here or sign up as a customer here.
HPE Aruba 9004 (RW) Gateway 4porte Ekstern
HPE Aruba 9004 (RW) - Gateway - 4 porte - 1GbE - ZigBee, NFC, Bluetooth - cloud-administreret - BTO
Specifications
Full specifications
|
General
|
|
|---|---|
|
Depth
|
15.31 cm
|
|
Device Type
|
Gateway
|
|
Height
|
3.82 cm
|
|
Weight
|
1.143 kg
|
|
Width
|
19.85 cm
|
|
Networking
|
|
|
Capacity
|
Number of supported devices: 2048 | Active firewall sessions: 32426
|
|
Cloud-Managed
|
Yes
|
|
Connectivity Technology
|
Wireless, wired
|
|
Data Link Protocol
|
Gigabit Ethernet, ZigBee, NFC, Bluetooth 5.0
|
|
Features
|
Firewall protection, Deep Packet Inspection (DPI), Quality of Service (QoS), fanless, gateway mode, SD-WAN support
|
|
Form Factor
|
External
|
|
Performance
|
Firewall throughput: 2 Gbps | Bridged throughput: 4 Gbps
|
|
Ports Qty
|
4
|
|
Status Indicators
|
Status, WAN, LAN
|
|
Internet of Things (IoT)
|
|
|
Communications Technology
|
Bluetooth, NFC, Zigbee
|
|
Internet of Things (IoT) Compatible
|
Yes
|
|
Expansion / Connectivity
|
|
|
Interfaces
|
4 x Ethernet 1000 - RJ-45 | 1 x USB 3.0 | 1 x console - RJ-45/micro-USB
|
|
Miscellaneous
|
|
|
Compliant Standards
|
EN 61000-3-2, NOM, EN 61000-3-3, EN55024, ICES-003 Class B, CCC, FCC Part 15, UL 60950-1, ANATEL, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class B, NCC, EN 301 489-1, CAN/CSA C22.2 No. 60950-1 Second Edition, EN 55032 Class B, CNS
|
|
Pricing Type
|
BTO
|
|
Power
|
|
|
Power Consumption Operational
|
25 Watt
|
|
Voltage Required
|
AC 120/230 V (50/60 Hz)
|
|
Manufacturer Warranty
|
|
|
Service & Support
|
Limited warranty - parts and labor - 1 year
|
|
Environmental Parameters
|
|
|
Humidity Range Operating
|
10 - 90% (non-condensing)
|
|
Max Operating Temperature
|
40 °C
|
|
Min Operating Temperature
|
0 °C
|
Media
HPE Aruba Networking 9004 (RW) 4-Port GbE RJ45 2K Clients - 32 APs Gateway
HPE Aruba Networking 9000 Series Branch Gateways provide high-performance networking, SD-WAN and security functionality in compact and cost-effective form factors. Ideally suited for branch and small campus networks, the 9000 series can be used as a wireless gateway for enhanced Wi-Fi scalability and security or for SD-WAN capabilities in the branch. Deploying this series as part of the HPE Aruba Networking SD-Branch solution is an affordable way to support multiple WAN connections, including the internet, MPLS, cellular, role-based policy enforcement, and path optimization. Designed with enterprise-grade capabilities and compact form factors, including an integrated LTE option, the 9000 Gateway can be easily configured and managed using HPE Aruba Networking Central, an AI-powered solution that simplifies IT operations, improves agility, and reduces costs by unifying management of all network infrastructure.
Versatile cloud-managed edge appliance can be deployed as an SD-Branch gateway or as a wireless gateway for greater scalability.
The gateway provides connectivity for up to 2,048 users or client devices with up to 6 Gbps of firewall throughput.
Layer 4-7 stateful firewall delivers a consistent user, device, and application awareness across WLAN, LAN, and WAN.
Dynamic Segmentation for automated role-based policy enforcement across users, devices, and IoT.
The 9004-LTE model provides integrated LTE connectivity for use as a dedicated or redundant WLAN uplink.
Versatile, Cost-effective Performance
- The HPE Aruba Networking 9000 Series Branch Gateways are compact edge appliances ideal for small enterprise or branch locations looking for enhanced security with optional integrated LTE connectivity.
- The gateway provides connectivity for up to 2,048 users or client devices with up to 6 Gbps of firewall throughput.
- It supports redundancy, clustering, and live upgrades for enhanced resiliency and high availability.
- The 9004-LTE model can a use high-speed LTE connection as either a dedicated or redundant WAN uplink for business continuity.
- IoT radio supports BLE technologies.
Flexible Deployments with Enhanced Security
- The HPE Aruba Networking 9000 Series Branch Gateways are ready for SD-Branch, WLAN, IPSec, and security use cases.
- Deploy as mobility controllers to increase wireless scalability and provide WLAN and LAN services such as Dynamic Segmentation, stateful firewall, and live upgrades.
- It is supported by the HPE Aruba Networking EdgeConnect SD-Branch solution that simplifies management of branch traffic. Gateways deployed in SD-WAN mode add role and identity-based intrusion detection and prevention capabilities (IDS/IPS) on top of existing security features.
- Offers enhanced security with Dynamic Segmentation to nearly eliminate the time-consuming and error-prone task of managing complex and static VLANs, ACLs, and subnets by dynamically assigning policies and keeping traffic secure and separated.
- Deep packet inspection provides greater application visibility and control. As a part of the policy enforcement firewall, the 9000 series consistently evaluates and improves performance and usage policies for over 3,800 applications.
AI-powered Cloud-based Management
- The HPE Aruba Networking 9000 Series Branch Gateways can be easily configured and managed using cloud-native HPE Aruba Networking Central that provides AI-powered insights, workflow automation, and robust security.
- Zero-touch provisioning simplifies deployment at branch sites that have few or no local IT resources.
- Wizard-based UI-driven workflows in HPE Aruba Networking Central NetConductor automate network design and policy creation, further streamlining network configuration and security operations from the cloud.
- The gateway supports WLAN and SD-WAN deployments with HPE Aruba Networking Central subscription licenses.
Lower Cost and Greater Efficiency with SD-Branch
- SD-branch technology provides a centrally-managed unified platform for SD-WAN, routing, security, LAN and Wi-Fi to deliver the ease of deployment, operations, and cost savings needed when managing large, distributed branch locations.
- The SD-Branch orchestrator seamlessly updates the overlay network across multiple branch locations, data centers, public clouds, and SaaS — delivering a consistent user experience and policy enforcement.
- Greater visibility into performance across every uplink in a branch to improve the reliability, re-routing traffic over a secondary link as necessary.
- Dynamic traffic steering based on roles, applications, and even IoT devices to prioritize traffic and improve user experience.
- Enhanced branch security with stateful application-aware firewall, Dynamic Segmentation, intrusion detection, web content filtering/classification and integration with third-party cloud security providers.
Specifications
| TechnicalSpecifications | |
|---|---|
| Ports | 4x 100/1000BASE-T ports |
| Mounting | Desktop (fanless), with optional mount rack tray |
| Input voltage | 12v DC, 2.5A AC-to-DC power adapter |
| Power consumption | 25W, maximum (with USB) |
| Certifications | FCC/ISED RED Directive 2014/53/EU Others: MIC, NCC, ANATEL, COFTEL, CCC |
| Regulatory | Safety Certifications: UL 60950‑1 Second Edition, CAN/CSA‑C22.2 No. 60950‑1 Second Edition, EN 60950‑1 Second Edition, EN 60950:2005, IEC 60950‑1 Second Edition, EN/IEC 62368‑1 2nd Edition, NOM (obtained by partners and distributors). Electromagnetic Emissions Certifications: FCC Part 15 Class B, CISPR32 Class B, EN55032 Class B, ICES-003 Class B, EN61000-3-2, EN61000-3-3, EN55024, EN301 489‑1/‑17, EN301 489‑52 (9004‑LTE), KN32 Class B, KN35, KN301 489-1/-17, KN301 489–52 (9004‑LTE) K, CNS13438 Class B. Telco: Common Language Equipment Identifier (CLEI) Code. Wireless Certifications: FCC/ISED, RED Directive 2014/53/EU. Others: MIC, NCC, ANATEL, COFTEL, CCC. |
| Product dimensions (metric) | 3.82 x 19.9 x 15.3 cm |
| Weight | 1.24 kg |
