Produktbeskrivelse
|
HiPower SP-750 - strømforsyning - 750 watt
|
|
Enhedstype
|
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
|
|
Specifikationsoverensstemmelse
|
ATX12V 2.4
|
|
Vægt
|
1.48 kg
|
|
Indgangspænding
|
AC 100/240 V
|
|
Udgangspænding
|
+3.3, +5, ±12 V
|
|
Strømkapacitet
|
750 watt
|
|
Output Current
|
+3.3V - 20 A<br>+5V - 18 A<br>+12V - 60 A<br>-12V - 0.3 A<br>+5VSB - 2.2 A
|
|
Output-stikforbindelser
|
1 x strøm 24 pin ATX med aftagelig 4 pin sektion<br>1 x strøm 8 pin +12 V med aftagelig 4 pin sektion<br>1 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion<br>6 x 15 pin Serial ATA strøm<br>6 x 4-PIN intern strøm<br>1 x 4-PIN mini-strømforsyningsforbinder<br>1 x 6 pin PCI Express-strøm
|
|
Kølesystem
|
120 mm ventilator
|
|
Udstyr inkluderet
|
Kabelbånd
|
|
Dimensioner (B x D x H)
|
15 cm x 14 cm x 8.6 cm
|
|
Producentgaranti
|
2 års garanti
|
Effective Friday, July 3, 2026, the office will close at 4:30 PM on Fridays. From Monday to Thursday, Sales contact hours remain unchanged from 9:00 AM to 5:00 PM, while contact hours for Accounting, Purchasing, and RMA remain unchanged in general.
To gain full access to our webshop, find our entire product range and see our prices, you need to be logged in.
Log in to your account here or sign up as a customer here.
HiPower SP-750 750Watt
HiPower SP-750 - Strømforsyning (intern) - ATX12V 2.4 - AC 100/240 V - 750 watt - aktiv PFC
Specifications
Full specifications
|
General
|
|
|---|---|
|
Device Type
|
Power supply - active Power Factor Correction (PFC) - internal
|
|
PSU Form Factor
|
ATX
|
|
Specification Compliance
|
ATX12V 2.4
|
|
Power Device
|
|
|
Efficiency
|
86.6% at 50% Load, 84.8% at 20% Load, 83.3% at full Load
|
|
Frequency Required
|
50 - 60 Hz
|
|
Input Voltage
|
AC 100/240 V
|
|
Output Current
|
+3.3V - 20 A | +5V - 18 A | +12V - 60 A | -12V - 0.3 A | +5VSB - 2.2 A
|
|
Output Voltage
|
+3.3, +5, ±12 V
|
|
Power Capacity
|
750 Watt
|
|
Power Output Connectors Details
|
1 x power 24 pin ATX with detachable 4 pin section | 1 x power 8 pin +12V with detachable 4 pin section | 2 x 8 pin PCI Express power with detachable 2 pin section | 6 x 15 pin Serial ATA power | 6 x 4 pin internal power | 1 x 4 pin mini-power connec
|
|
Miscellaneous
|
|
|
Cables Included
|
Power cable
|
|
Cooling System
|
120 mm fan
|
|
Features
|
Overvoltage protection, overpower protection, short-circuit protection
|
|
Included Accessories
|
Cable ties
|
|
Manufacturer Warranty
|
|
|
Service & Support
|
Limited warranty - 2 years
|
|
Environmental Parameters
|
|
|
Sound Emission
|
19 dB
|
|
Dimensions & Weight
|
|
|
Depth
|
14 cm
|
|
Height
|
8.6 cm
|
|
Weight
|
1.48 kg
|
|
Width
|
15 cm
|
|
Dimensions & Weight (Shipping)
|
|
|
Shipping Weight
|
1.82 kg
|
