Produktbeskrivelse
|
ASRock X299 Taichi CLX - bundkort - ATX - LGA2066 Socket - X299
|
|
Produkttype
|
Bundkort - ATX
|
|
Chipsættype
|
Intel X299
|
|
Processor-socket
|
1 x LGA2066 Socket
|
|
Kompatible processorer
|
Core X
|
|
Max RAM-størrelse
|
256 GB
|
|
RAM understøttet
|
8 DIMM åbninger - DDR4, ikke-ECC, ikke bufferet
|
|
Lagringsporte
|
10 x SATA-600 (RAID), 3 x Ultra M.2
|
|
USB / FireWire porte
|
1 x USB-C Gen 2x2 + 1 x USB 3.1 Gen 2 + 4 x USB 3.0 + 2 x USB 2.0 + (1 x USB-C Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via samlekasser)
|
|
Audio
|
HD Audio (8-kanaler)
|
|
LAN
|
Bluetooth, Gigabit Ethernet, 2.5 Gigabit Ethernet, 802.11a/b/g/n/ax
|
Effective Friday, July 3, 2026, the office will close at 4:30 PM on Fridays. From Monday to Thursday, Sales contact hours remain unchanged from 9:00 AM to 5:00 PM, while contact hours for Accounting, Purchasing, and RMA remain unchanged in general.
To gain full access to our webshop, find our entire product range and see our prices, you need to be logged in.
Log in to your account here or sign up as a customer here.
ASRock X299 Taichi CLX ATX LGA2066 Intel X299
ASRock X299 Taichi CLX - Bundkort - ATX - LGA2066 Socket - X299 Chipset - USB-C Gen2, USB 3.2 Gen 1, USB 3.2 Gen 2 - Bluetooth, Gigabit LAN, 2.5 Gigabit LAN, Wi-Fi - HD Audio (8-kanaler)
Product no:
995428616
Model:
90-MXBBH0-A0UAYZ
EAN:
4717677339765
Brand:
Weight:
3.04 kg
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Specifications
Full specifications
|
General
|
|
|---|---|
|
Chipset Type
|
Intel X299
|
|
Compatible Processors
|
Core X
|
|
Max Processors Qty
|
1
|
|
Processor Socket
|
LGA2066 Socket
|
|
Product Type
|
Motherboard - ATX
|
|
Supported RAM
|
|
|
Bus Clock
|
2400 MHz, 2133 MHz, 2666 MHz, 2800 MHz (O.C.), 2933 MHz (O.C.), 3200 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3800 MHz (O.C.), 4000 MHz (O.C.), 4200 MHz (O.C.)
|
|
Features
|
Quad channel memory architecture, Intel Extreme Memory Profiles (XMP) 2.0
|
|
Max Size
|
256 GB
|
|
Registered or Buffered
|
Unbuffered
|
|
Supported RAM Integrity Check
|
Non-ECC
|
|
Technology
|
DDR4
|
|
Audio
|
|
|
Audio Codec
|
Realtek ALC1220
|
|
Compliant Standards
|
DTS Connect, High Definition Audio, Premium Blu-ray audio support, Purity Sound 4
|
|
Type
|
HD Audio (8-channel)
|
|
LAN
|
|
|
Network Controller
|
Intel I219V / Dragon RTL8125AG
|
|
Network Interfaces
|
Bluetooth, Gigabit Ethernet, 2.5 Gigabit Ethernet, 802.11a/b/g/n/ax
|
|
Expansion / Connectivity
|
|
|
Expansion Slots
|
1 x CPU | 8 x DIMM 288-pin | 4 x PCIe 3.0 x16 (44-lane CPU (x16/x8/x16/x0, x8/x8/x16/x8 modes), 28-lane CPU (x16/x0/x8/x0, x8/x0/x8/x8 modes), 16-lane CPU (x16/x0/x0/x0, x8/x0/x4/x0 modes)) | 1 x PCIe 3.0 x1 | 1 x M.2 socket
|
|
Interfaces
|
USB-C Gen2x2 | 1 x TOSLINK | 2 x USB 2.0 | 4 x USB 3.2 Gen 1 | 1 x LAN (Gigabit Ethernet) | 1 x audio line-out (rear) - mini-jack | 1 x audio line-out (center/subwoofer) - mini-jack | 1 x audio line-in - mini-jack | 1 x audio line-out (front surround
|
|
Internal Interfaces
|
2 x USB 3.2 Gen 1 - header | 4 x USB 2.0 - header | 1 x audio - header | 1 x Thunderbolt - header | 1 x USB-C Gen2 - header
|
|
Power Connectors
|
24-pin main power connector, 2 x 8-pin ATX12V connectors
|
|
RAID Features
|
Intel Smart Response Technology
|
|
Storage Interfaces
|
SATA-600 -connectors: 8 x 7pin Serial ATA - 8 devices - RAID 0 / RAID 1 / RAID 10 / RAID 5 | ASMedia ASM1061: SATA-600 -connectors: 2 x 7pin Serial ATA - 2 devices | PCIe 3.0 -connectors: 2 x Ultra M.2 | SATA-600 / PCIe 3.0 -connectors: 1 x Ultra M.2
|
|
Features
|
|
|
BIOS Features
|
Multilingual BIOS, UEFI BIOS, Dual BIOS, Secure Backup UEFI Technology, SMBIOS 3.0 support, ACPI 6.1 support
|
|
BIOS Type
|
AMI
|
|
Hardware Features
|
ASRock Instant Flash, NVIDIA 3-way SLI Technology Support, Intel Extreme Memory Profile (XMP) support, AMD 3-way CrossFireX technology support, ASRock Internet Flash, Digi Power Design, ESD Protection, Gold Plated Audio Hardware, Energy Efficient Eth
|
|
Hardware Monitoring
|
CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage
|
|
Manual Settings
|
Processor core voltage, memory voltage, chipset voltage
|
|
Sleep / Wake Up
|
Wake on LAN (WOL)
|
|
Miscellaneous
|
|
|
Cables Included
|
4 x Serial ATA cable
|
|
Compliant Standards
|
FCC, EuP Ready, ErP Ready
|
|
Depth
|
24.4 cm
|
|
Included Accessories
|
I/O back plate, ASRock WiFi 2.4/5GHz Antenna, 3 x M.2 screws, ASRock SLI_HB_Bridge_2S Card, screwdriver, 3 x standoff for M.2 socket
|
|
Software Included
|
Drivers & utilities, ASRock A-Tuning, Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar
|
|
Width
|
30.5 cm
|
