Smart-UPS er en strømforsyningsbeskyttelse med høj ydelse til beskyttelse af erhvervskritisk udstyr. Smart-UPS er en online-UPS som kan anvendes enten som fritstående enhed eller som rackmontering.
Product no 527184
Model SMX1500RMI2UNC
Brand APC
EAN 0731304281702
Weight 32.08 kg
Produktbeskrivelse | APC Smart-UPS X 1500 Rack/Tower LCD - UPS - 1200 Watt - 1500 VA |
Enhedstype | UPS - rackversion |
Rackstørrelse | 2U |
Vægt | 24.8 kg |
Indgangspænding | AC 230 V |
Udgangspænding | AC 230 V |
Strømkapacitet | 1200 Watt / 1500 VA |
Input-stik | Strøm IEC 60320 C14 |
Output-stikforbindelser | 8 x power IEC 60320 C13 |
Batteri | Blysyre |
Batteri formfaktor | Indstiksmodul |
Antal batterier | 1 |
Driftstid (op til) | 5.8 min ved fuld belastning |
Netværk | Ethernet, RS-232, USB |
Farve | Sort |
Dimensioner (B x D x H) | 8.9 cm x 49 cm x 43.2 cm |
Producentgaranti | 3 års garanti |
Designet for | P/N: AR106SH6, AR106V, AR106VI, AR109SH6, AR112SH6, AR3003, AR3003SP, AR3006, AR3006SP, AR3103, AR3103SP, AR3106, AR3106SP, AR3140G, AR3340G, AR3357X674, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4024IX431, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4038IX432, NBWL0356A |
General | |
---|---|
Battery Enclosure Type | Plug-in module |
Color | Black |
Device Type | UPS - rack-mountable |
Height (Rack Units) | 2U |
Power Device | |
Circuit Protection | Circuit breaker |
Frequency Provided | 47 - 63 Hz |
Frequency Required | 50/60 Hz |
Input Connectors | Power IEC 60320 C14 |
Input Voltage | AC 230 V |
Input Voltage Range | AC 160 - 285 V |
Input Voltage Range (Adjustable) | AC 151 - 302 V |
Output Voltage | AC 230 V 47 - 63 Hz |
Output Waveform | Sinewave |
Power Capacity | 1200 Watt / 1500 VA |
Power Output Connectors Details | 8 x power IEC 60320 C13 |
Surge Energy Rating | 645 Joules |
Surge Suppression | Yes |
UPS Technology | Line interactive |
Battery | |
Quantity | 1 |
Recharge Time | 3 hours |
Run Time (Up To) | 5.8 min at full load | 17.2 min at half load |
Technology | Lead acid |
Networking | |
Remote Management Interface | Ethernet, RS-232, USB |
Expansion / Connectivity | |
Expansion Slots | 1 (total) / 0 (free) x SmartSlot |
Interfaces | 1 x management (RS-232) | 1 x management (USB) | 1 x EPO (emergency power off) | 1 x management (Ethernet) - RJ-45 |
Miscellaneous | |
Cables Included | Serial cable - external | USB cable - external | Power cable - integrated - 1.8 m |
Compliant Standards | C-Tick, UL 1449, VDE, EN 50091-2, RoHS Exemption 7b, EN 50091-1 |
Features | Audible alarm, emergency power off, LCD display |
Rack Mounting Kit | Included |
Software / System Requirements | |
Software Included | APC PowerChute Business Edition |
Manufacturer Warranty | |
Service & Support | Limited warranty - 3 years | Limited warranty - batteries - 2 years |
Environmental Parameters | |
Humidity Range Operating | 0 - 95% |
Max Operating Temperature | 45 °C |
Min Operating Temperature | 0 °C |
Sound Emission | 40 dBA |
Dimensions & Weight | |
Depth | 49 cm |
Height | 43.2 cm |
Weight | 24.8 kg |
Width | 8.9 cm |
Dimensions & Weight (Shipping) | |
Shipping Depth | 62 cm |
Shipping Height | 58.9 cm |
Shipping Weight | 30 kg |
Shipping Width | 24.6 cm |
Compatibility Information | |
Designed For | P/N: ACDC2513, AR106SH6, AR106V, AR106VI, AR109SH6, AR112SH6, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR3003, AR3003SP, AR3006, AR3006SP, AR3100G, AR3100TAA, AR3100W, AR3103, AR3103S |
